ADC valve can offer you full range of required valves like Ceramic valves, Knife gate valves, Strainers, Plug valves, Segment valves, Diaphragme valves and another

Knife gate valves

Design acc MSS SP 81

Connection: Wafer type; Lug type; Flanged type.

DN: 50 - 1800 (bigger by request)

Pressure: PN2,5 - PN6 - PN10 - PN16 - PN20 - PN25 - PN40 - PN64;

Class 150 - 300 (Up to 64 Bar)

Body: GG20; GGG40; GGG50; WCB; LCC; CF8; CF8M; Aluminium Bronze; Duplex; Hastelloy; Special alloys. (Cast iron, Ductile iron, carbon steel, stainless steel, alloys).

Seat EPDM, NBR, VITON, SILICONE, PTFE, METALL TO METALL

Zero leakage, rate A. (*For soft seat)

Operation: Bare shaft, lever, handwheel, gearbox, pneumatic actuator, electric actuator (AUMA, ROTORK, BERNARD, another world famous manufacturers, or local Chinese brand).

Uni-directional and Bi-directional

Medium / Industry: Water; Chemical; Pulp and paper; Mining.

STRAINERS

Connection: Flanged type or welded type

DN: 10 - 1200 (bigger by request)

Pressure: PN2,5 - PN6 - PN10 - PN16 - PN20 - PN25 - PN40 - PN64 - PN100 - PN160 - PN240 - PN420. Class 150 - 300 - 600 - 900 - 1500 - 2500

Body: GG20; GGG40; GGG50; WCB; LCC; CF8; CF8M; Aluminium Bronze; Duplex; Hastelloy; Special alloys. (Cast iron, Ductile iron, carbon steel, stainless steel, alloys).

DN: 50 - 1800 (bigger by request)

Pressure: PN2,5 - PN6 - PN10 - PN16 - PN20 - PN25 - PN40 - PN64. Class 150 - 300.

Body: GG20; GGG40; GGG50; WCB; LCC; CF8; CF8M; Aluminium Bronze; Duplex; Hastelloy; Special alloys. (Cast iron, Ductile iron, carbon steel, stainless steel, alloys).
